Key Features:
High Density: 18.1 g/cm³ for superior weight and radiation shielding properties.
Exceptional Strength: Yield stress of 570 MPa and maximum traction load of 900 MPa.
Excellent Elongation: 15% elongation over 25 mm for enhanced flexibility.
High Hardness: 27 HRC for wear resistance and durability.
Thermal and Electrical Conductivity: 93 W/m·K heat conductivity and 177Ω>14% IACS electrical conductivity.
Applications:
Radiation shielding in medical and nuclear industries.
Aerospace components require high strength and durability.
Defense equipment such as armor-piercing projectiles.
Industrial tooling for cutting tools and dies.
Technical Specifications:
| Property | Value |
|---|---|
| Composition | 95% W, 3.5% Ni, 1.5% Fe |
| Density | 18.1 g/cm³ |
| Yield Stress | 570 MPa |
| Maximum Traction Load | 900 MPa |
| Elongation over 25 mm | 15% |
| Hardness | 27 HRC |
| Heat Conductivity | 93 W/m·K |
| Electrical Conductivity | 177Ω>14% IACS |
Why Choose WHD-11?
WHD-11 combines high density, mechanical strength, and excellent thermal properties, making it a versatile solution for the most challenging environments. Whether you need reliable radiation shielding or durable industrial components, WHD-11 delivers unmatched performance.
For more information about High-Density Tungsten Alloy Meterial grade WHD-11, please feel free to contact us at +86 18673339477 or sales@ejtungsten.com
